| Cable Type RF |
WRC-45
RG-196 |
WRC-46
RG-188 |
WRC-47
RG-141 |
WRC-48
RG-142 |
WRC-56
RG-140 |
WRC-55
RG-187 |
WRC-59
RG-195 |
| Cond. Type |
SPCW |
SPCW |
SPCW |
SPCW |
SPCW |
SPCW |
SPCW |
| Cond.Size (No./mm) |
7/0.10 |
7/0.17 |
1/0.96 |
1/0.96 |
0.64 |
7/0.10 |
7/0.10 |
| Dielectric Ins., OD in mm |
0.86 |
1.52 |
2.94 |
2.94 |
3.70 |
1.52 |
2.59 |
| Screen Braid |
SPC |
SPC |
SPC |
SPC |
SPC |
SPC |
SPC |
| Screen OD in mm (Max.) |
1.37 |
2.06 |
3.71 |
4.34 |
4.47 |
2.13 |
3.15 |
| Jacket Type |
PTFE |
PTFE |
PTFE |
PTFE |
PTFE |
PTFE |
PTFE |
| Jacket OD in mm (Max.) |
2.03 |
2.79 |
4.82 |
4.95 |
5.91 |
2.79 |
3.94 |
| Capacitance (PF/m) (Nom.) |
95.00 |
95.00 |
93.50 |
93.50 |
68.90 |
65.60 |
52.50 |
| Impedance In OHMS (+/-4) |
50 |
50 |
50 |
50 |
75 |
75 |
95 |
| Attenuation At 400 MHZ db/100 m (Max.) |
103 |
65.6 |
29.5 |
29.5 |
26.20 |
68.90 |
55.80 |
| Cont. Working Voltage In Vrms |
750 |
900 |
1400 |
1400 |
1700 |
900 |
1100 |
| Max.Oper. Frequency in GHZ |
3 |
3 |
3 |
12.4 |
3 |
3 |
3 |
